Quartz Spiral Tube

Quartz Spiral Tube

① Exceptional High - Temperature Resistance
② Superior Chemical Resistance
③ Unique Spiral Structure
④ High Purity and Transparency
⑤ Precise Dimensional Accuracy

Description

Functions



  • Heat Transfer Enhancement
  • Gas and Liquid Mixing
  • Reaction Acceleration



Uses



  • Semiconductor Manufacturing
  • Chemical Industry
  • Solar Energy Industry
  • Laboratory Research



Product Advantage



  • Customization Flexibility
  • High - Quality Assurance
  • Cost - Effective Performance
  • Fast and Reliable Delivery



Application Areas



  • Petrochemical Industry
  • Pharmaceutical Industry
  • Environmental Engineering



Properties



Physical Properties

Values

Purity

>99.99%

Density

2.2g/cm3

Transparency

>90%

Mohs Hardness

5.5--6.5

Deformation Point

1280℃

Softening Point

1750℃

Annealing Point

1250℃

Specific Heat (20 - 350°C)

670J/kg.℃

Thermal Conductivity (20°C)

1.4W/m.℃

Heat Conductivity (w/m.k,1000 ℃ )

1.0-1.2

Refractive Index

1.4585

Coefficient of Thermal Expansion

5.5*10 -7cm/cm.℃

Hot - working Temperature

1750--2050℃

Short - term Service Temperature

1450℃

Long - term Service Temperature

1100℃



Chemical Properties

Values

Acid resistant

Strong Acid(except HF),Strong alkali, organic solution

High temperatures Corrosion resistant

Excellent

Metal Impurity Content

<5 ppm



Electrical Properties

Values

Resistivity

7*107Ω.cm

Insulation Strength

250~400Kv/cm

Dielectric Constant

3.7~3.9

Dielectric Absorption Coefficient

<4*10-4

Dielectric Loss Coefficient

<1*10-4



Mechanical Properties

Values

Compressive Strength

1100MPa

Bending Strength

67MPa

Tensile Strength

48MPa

Poisson's Ratio

0.14~0.17

Young's Modulus

72000MPa

Shear Modulus

31000MPa



FAQ

Q1: What is the maximum pressure that the quartz spiral tube can withstand?

A1: The maximum pressure - bearing capacity of our quartz spiral tubes depends on factors such as the outer diameter, wall thickness, and the specific design. Generally, our standard tubes can withstand a certain range of pressures. For detailed information on the pressure - bearing capacity for your specific requirements, please contact us, and we will provide you with accurate data.

Q2: How do I clean the quartz spiral tube?

A2: You can clean the quartz spiral tube using a mixture of non - abrasive cleaning agents, such as hydrochloric acid, nitric acid (with the concentration controlled within 5%), or other suitable solvents. During the cleaning process, take proper protection measures to avoid skin contact with the cleaning agents. After cleaning, rinse the tube thoroughly with deionized water to ensure there is no residue left, which could affect its performance. Note that the cleaning wastewater containing acids should be treated properly to meet environmental protection requirements before discharge.

Q3: Can the quartz spiral tube be used for food - related applications?

A3: Yes, due to its high - purity and non - toxic properties, our quartz spiral tubes can be used in food - related applications, such as food processing and beverage production. However, it is important to ensure that the tube is properly cleaned and maintained in accordance with food safety standards.
